Universal Vice UN1 for Milling and Drilling

Universal Vice UN1 for Milling and Drilling

Universal Vice UN1 (catalogue model 30) has a 100 mm jaw width and 100 mm opening for milling and drilling workholding. Share your machine and component details with Engeetech for technical quotation.

Categories
Request a technical quote ↗

Universal Vice UN1 (also listed as a universal vise) is Engeetech catalogue model 30 with a 100 mm jaw width and 100 mm opening for milling and drilling workholding. Confirm the machine interface, component geometry and setup requirements before quotation.

Use this universal vise for milling, drilling, toolroom and adaptable small-batch setups. Contact Engeetech with your machine and component details for technical selection and an RFQ.

Universal Vise Series selection notes

  • Universal vise platform listed in the Engeetech brochure
  • Brochure-listed jaw and opening options for technical review
  • Selection depends on the component and machine setup
Catalogue Number 30
Series Universal Vise Series
Reference Engeetech Final Brochure
Base Width 100 mm
Jaw Width 100 mm
Opening 100 mm
Full Length 280 mm
Full Height 180 mm
Bed Length 265 mm
Vise Bed Height 138 mm
Jaw Height 42 mm
Accuracy 0.02/100 mm
Material Ductile iron SG500/7; hardened jaw HRC 50-52
Weight 21 kg (approx.)

Choose a workholding platform around the way your machine actually runs. These applications are the starting point for selecting the right Engeetech configuration.

  • General milling and drilling
  • Tool room workholding
  • Adaptable component setups
  • Small-batch manufacturing
